Combine Harvesting Machine for Wheat Rice Bean

QQ图片20180330161709.pngBasic Info

  • Model NO.: 4LZ-2.3

  • Application: Rice, Wheat, Soybean

  • Harvest method: Cutting

  • Transmission: Hard Shaft

  • Color: Red

  • Application Field: Agriculture

  • Power: 88 HP

  • Cutting Width: 2000 mm

  • Working Speed: 0.86-2.5 M/S

  • Driving: One Person

  • Loss Ratio: 1%

  • Specification: CE

  • HS Code: 8433510090

  • Type: Vertical Cut Harvester

  • Power Source: Diesel

  • Drive Type: Gear Drive

  • Certification: ISO9001:2008, CE

  • Condition: New

  • Feeding Capacity: 2.3 Kg/S

  • Harvesting Capacity: 0.33-0.65 Hm2/H

  • Rubber Track: 450*90 mm

  • Minimum Ground Clearance: 260 mm

  • Mode of Turning: Hydraulic Steering

  • Trademark: Chengshida

  • Origin: China

Product Description

combine harvesting machine for wheat rice bean


1) Big Size Grain Tank
2) Rubber track for wet paddy rice field
3) Combined rice paddy cutting and threshing
4) Good after-sale service
5) Easy driving and transportation

Technical parameters:

Working efficiency (ha./h)0.35~0.65
Cuting width (mm)2000
EngineTypeWater cool, four stroke, diesel engine
Displacement (L)2.98/3.16
Output/rpm (hp)88
Fuel tank capacity (L)40
Traveling systemCrawler specification450mm*90mm*48

(width*pitch*No.of tooth)
Ground pressure (kpa)21
Ground clearance260mm
Transmission4 forward, 2 reverse OR HST
Working partsThreshing cylinderTypeAxial flow, spike tooth
Diameter& length550mm*1285mm (Double)
CleaningChaffer sieve + fan( front blowing and rear suction) + two times vibrate
Fuel consumption (kg/ha.)22~42
Working speed (m/s)0.5~1.2
Blade cutting space(mm)76.2
Screw conveyer typerExtendible transverse conveyer
Screw conveyer outside diameter(mm)490
Grain tank capacity (cubic meter)1.1
Wet field passing15cm
Grain unloading methodSacks OR auto unloading auger
Total loss (%)Rice≤2, Wheat≤1
Breakage rate (%)≤1
Impurity rate (%)Rice≤1, Wheat≤1
Use reliability(%)≥93
Optional deviceContinuosusly Variable Transmission, rape harvesting assembly, 1.8m reap fitting, 2.2m reap fitting, #498 Diesel Engine, One-lever entire operation system, external discharge screw conveyer, 400mm-width track (2 pieces),lengthened #03 thresher assembly,small tanker,single blade.

Packing and shipping:

3 sets in one 40"HQ container

Our services:

1. One year guarantee for main parts of the harvester
2. Engineers available to service overseas for large quantity order

BV, CCC, ISO, CE,etc

Weifamg Shengchuan Machinery C0., LTD

abby yang:

wechat: 1304061398

whatsapp: +8615169566796

skype: abbyyang 111

mobile: 008615169566796


1. How can we learn to drive this harvester?
Answer: You are welcome to our factory, and then we will supply room and board and train you all free.
2.Do we have to buy quick-wear parts with the machine?
Answer: Yes and we will send you some parts free of charge.
3.Is there any discount?
Answer: Discount is according to the quantity you purchase.
4.How is the quality of the harvesrter?
Answer: We have been in this field for many years and can supply high quality harvester for you.
You just have to change the quick-wear parts timely.
