Crawler 0.4kg/S Feeding Capacity Mini Combine Harvester

Basic Info

  • Model NO.: 4LZ-0.4

  • Application: Rice, Wheat

  • Harvest method: Cutting

  • Transmission: Hard Shaft

  • Certification: SGS, ISO9001:2008, CE

  • Condition: New

  • Engine Power: 4.5kw

  • Weight: 330kgs

  • Specification: CE SGS ISO

  • HS Code: 8433510090

  • Type: Hand-Type Harvester

  • Power Source: Diesel

  • Drive Type: Gear Drive

  • Portable Harvester Type: Self Propelling

  • Color: Red

  • Application Field: Agriculture

  • Cutting Width: 0.13m

  • Trademark: WISHOPE

  • Origin: Chongqing

Product Description

Crawler 0.4kg/s Feeding Capacity Mini Combine Harvester

Self-propelled Mini Combined Harvester 4LZ-0.4 Specifications
GeneralHarvest Rating≥0.05 ha/h
EngineTypeAir-cooled Gasoline
Fuel Consumption≤30 kg/haModel177F/P
Dimensions2630×1050×1500mmRated Power4.5 kW
Weight330 kgRated Speed3600 r/min
Harvesting Scope835 mmThresherDrumTypeAxial-flow And Teeth
Minimum Ground Clearance
150 mmDiameter x Length360×630mm
Feeding Weight0.4 kg/sTeeth Length70 mm
Shifts1, 0, 2, 0, -1Teeth Quantity28
Walking Speed At Work0.4~0.6 m/sSpeed1220 r/min
CutterTypeReciprocationConcave TypeGrid
Lifting TypeManual HydraulicDischargerFanTypeCentrifugal
CutterTypeModel VI VIDiameter245 mm
Quantity2Speed3300 r/min
Screw ConveyorTypeScrewQuantity1
Speed246 r/minLifterTypeScraper Blades
Clearance8 mmLoading TypePreset Bag
FeederRod Angle90°WalkingCrawler BeltLength x PCs x Width75mm×28pcs×250mm
Rod Length130 mmTrack Gauge570 mm
Rod Gap175 mmTransmission GearboxStep speed change
 With reverse gear
Chain Speed0.8 m/sWalking Clutch TypeTensioner
DividerAvailableOperating Typehand-operation and step with device
Working Clutch TypeTensionerSteering TypeDrum Clutch

More Photos:

About Us:
WuHan Wishope is one branch company of Wishope International Group Limited, mainly engaged agricultural machinery production and trading.

Our business contains: Sales of all kinds of farming machines and related spare parts, specially professionally in full feeding crawler combine harvester, rice transplanter, tractor & power tiller, and also spare parts of brandedd farming machines such as Kubota, YanMar, Daedong, John Deere, Mubota, Xingguang.

Major market covers South East Asia, Middle East, as well as Southern Asia. With rich experience of exporting and excellent before-sales and after-sales service. It brings us very good reputation.

1.Q: What is the warranty of the agricultural machinery?
  A: One year guarantee for whole machine (except quick-wear parts), engine model and gear box.
Tips: we usually suggest the buyer order some quick-wear parts separately.
2.Q: Is there any option for your combine?
  A: Yes, option parts such as: rubber track, grain tank and type of grain unloading
3.Q: What is your delivery time?
A: Normally, it takes 15-20days to delivery after your deposit receipt or L/C at sight
4.How many harvesters can be loaded in one container?
1)20 Feet Container loads:
For Combine: 5 sets 4LZ-0.4; 8sets 4LZ-0.8; 1set 4LZ-1.2; 1set 4LZ-2.2; 1set 4LZ-3.0; 1set 4LZ-4.0/4.5
2) 40 High Cube Container loads:
For Combine: 11sets 4LZ-0.4; 20sets 4LZ-0.8; 4sets 4LZ-1.2; 4sets 4LZ-2.2, 3sets 4LZ-3.0, 3sets 4LZ-4.0/4.5
5.Q: What is the payment item?
  A: Irrevocable L/C at sight or 30% T/T in advance and balance against B/L copy.
6.Q: What is the after-sales service?
  A: Every year we send our engineer and after-service people to local market two times, to assist our sales agent training staff, marketing, advertising, maintaining and repairing the machine during the harvesting season.
7.Q: Is OEM or ODM service acceptable?

  A: OEM service is no problem, if you have any special requirement about the machine, please kindly inform us, our engineer department will study and offer your suitable solution.
