Managed Media Converter with 2 Fiber Ports and 6 Ethernet Ports

Product Details



Key Specifications/Special Features:

Product description

NT-M2600 is an L2 Web-Smart Media Converter with switch function. With 1.6Gbps non-blocking switch fabric, 1K MAC Address table and 802.3x Full-Duplex flow control, the NT-M2600 offers wire-speed packet transfer performance without risk of packet loss. 2 100Base-FX Fiber ports extend the transmission distance of network up to 100km.For efficient management, with its built-in web-based management, the NT-M2600 offers an easy-to-use and configuration facility. Via the WEB interface the NT-M2600 can be programmed for basic switch management functions such as per port speed duplex settings,VLAN, QOS, broadcast storm and bandwidth control to enhance bandwidth utilization.


  • 155M at fiber port, 10/100/M self-adaptive at Ethernet ports, Half/Full-Duplex self-adaptive

  • About 1K MAC address capacity, update automatically

  • Support Broadcast storm protection

  • The max-rate data transmission (wire-speed): 148 800 frm/s (100M), 14,880 frm/s (10M)

  • Support 1552byte VLAN Data Frame transmission (hardware configuration:    1552/1536BYTE)

  • Support dividing into 16 groups VLAN, support QoS & port blocking

  • Support Store-and-Forward Working Mode; support Half/Full Duplex; support 802.3x flow control under Full Duplex working mode; support auto-sensation of MDI/MDIX

  • Support Filter/forward special DA option

  • Network line status LED: transmission rate indicator(10/100M); Fiber and twisted-pair's connection status

  • Support 8-level bandwidth control: 128K, 256K, 512K, 1M, 2M, 4M, 8M, full speed

  • Support 6 Ethernet ports communications simultaneously, using for connecting NIC, switch, and HUB

  • Support the IEEE802.1q, which can guarantee the backbone features of most mainstream products, such as inter-switch's VLAN function

  • High-capacity network caching technology ensures data transmission and multimedia applications

  • Non-blocking switch, ensuring data-transmission's security and stability


IEEE 802.3 10Base-T Ethernet,

IEEE 802.3u 100Base-TX Fast Ethernet,

IEEE 802.3u 100Base-FX,

IEEE 802.3x flow control,

IEEE802.1q tagged VLAN,

IEEE 802.1p Class of service
Port6-port RJ45(100Base-TX); 2-port SC, ST, FC, or SFP (100Base-FX)
LED IndicatorPOWER: Green light
LINK/ACT: Green light, indicator for data transmission, showing fiber or Twisted Pair's connection status;
Light off indicates fiber or Twisted Pair no-connection
Light on indicates fiber or Twisted Pair normal connection
Light blink indicates the data is transmitting at Ethernet/fiber  port
10/100M: Green light, Indicator for Ethernet or fiber port transmission rate
Light off indicates transmission rate is 10M
Light on indicates transmission rate is 100M
Switch mechanism
Store and Forward
Power supplyPower Adaptor: 5V; 10W
Operating temperature
Maintaining temperature-40~70℃
Humidity5%~90%  Non-condensing
95mm(W)×30mm(D)×170mm(H) (Shell Thickness 1mm)
