OAM standalone managed fiber media converter

Product Details

Key Specifications/Special Features:

NT-LM105 is remote managed 10/100M auto-negotiation Ethernet fiber media converter with OAM functions developed by our company.  Remote devices can be managed by fiber-connected media converters/switches (which must support IEEE802.3ah standard).
1. Offer one Ethernet port, one 100BASE-FX, 100BASE-SX/LX optical port or SFP port.
2. Support 4 kinds of OAM functions: Discover of OAM, MIB variable response, OAM Loopback, dying GASP alarm.
3. Supports optional LFP feature
4. Supports Jumbo frame transmission
5. Supports MDI/MDIX UTP cable
6. Supports SC\ST\FC\SFP port

Functional characteristics
1. Supports LFP function.
2. Supports Q-in-Q function, optical port and Ethernet port can be set separately as dual tag ports, and can be set as ISP tag and ISP tag TPID at will.
3. Can query and configurator the operation mode of each port on local and remote devices, including port speed, full/half-duplex, and flow control, and more, and can display the real-time status of each port.
4. Support bandwidth-limiting function:  with the step of 64kps, the bandwidth can be set between 0Mbps and 100Mbps at will.
5. Offer MIB library files, support OpenView, SNMPC, and other software’s.
6. Supports link line-speed loopback, convenient for line debugging

Structure size32mm×127mm×156mm
Optical portSC/PC, ST/PC, FC/PC, SFP
Working temperature
-40, 80ºC
Power dissipation (W)Typical value: 5W
Relative humidity
5%~90% no condensing

Primary Competitive Advantages:

  • Form A

  • Guarantee/Warranty

  • International Approvals

  • Military Specifications

  • Packaging

  • Price

  • Product Features

  • Product Performance

  • Prompt Delivery

  • Quality Approvals

  • Reputation

  • Service

  • Small Orders Accepted

  • Distributorships Offered

  • Electronic Link

  • Experienced Staff

Main Export Markets:

  • Western Europe

  • Asia

  • Australasia

  • Central/South America

  • Eastern Europe

  • Mid East/Africa

  • North America

Payment Details:

  • Payment Terms:Telegraphic Transfer in Advance (Advance TT, T/T)

  • Minimum Order:1        Pieces

Delivery Details:


  • FOB Port:Shenzhen

  • FOB  Range: US$ 25 - US$ 60 per unit (Pieces)

  • Lead Time: 2        -        7        days
