OEM network hardware/managed switch

Product Details


Key Specifications/Special Features:

  • This product, based on high-performance ASIC chip technology, with the modular structure design, provides 20 10/100/1000M RJ45 ports, 4 1000M combo ports, and 4 10GE SFP+ ports (2 integrated 10GE ports, 2 extensible 10GE ports), having a capability of multilayer switching and wire-speed routing forwarding. At the same time, this product can provide a complete IPv4/IPv6 routing, including tunnel and IP multicast

  • User can set the various functions of switches through the Web, SNMP etc. UK5704-28TC also supports L2 and L3 VPN, DOS defense, static routing, RIP, OSPF, BGP, PIM-SM, PIM-DM, DVMRP, NAT, Qos, RSTP, MSTP, VLAN, Port Security, storm suppression, ACL access control and other functions

  • High performance

  • With 128G backplane bandwidth

  • Hardware routing, wire-speed 3rd layer switching packet forwarding rate of 95.232Mpps

  • Can be deployed in the core of metropolitan area network, and provides several final 1 km Technology

  • Safety

  • Provide DOS, distributed denial of service, deception and virus defense

  • Support IEEE802.1x, provide port-based user authentication, network shield, safety control, and strategy control technology

  • Restrict maximum number of connected hosts port, with multi-channel Ethernet interface binding, increasing bandwidth and system redundancy

  • Powerful ACL, support for L2-L4 layer data filtering

  • Support QinQ function

  • Strategy control list, flow regulation

  • Convenient use and maintenance

  • Use clustering technology, support for more than one device stack, with a unified IP Address  to carry on centralized management and address resources savings

  • All kinds of management method through Web, SNMP and so on

  • Support XModem protocol, can be used to upgrade software and BootRom by TFTP/ZMODEM

  • Support DHCP server and relay functions, dynamic allocation of IP address

  • Support SFP+, but also downward compatible XFP(6) provide redundant power supply, quick failover and quick connection, greatly increasing the reliability of the system

  • Powerful flow and broadcast management

  • Automatic detecting and broadcast storm restraining, support for IGMP message detection, effectively limit the spread of broadcast message.

  • Support full duplex mode and half duplex mode flow control

  • Support Ethernet interface with 1M as the rate limiting step

  • Advanced buffer management, support 802.1p protocol, 8 transmit queues per port mapping 802.1p 8 priority

  • Support IP multicast and QoS

  • Kinds of routing strategy

  • Support static routing

  • Support RIP v1/v2, OSPFv2, BGPv4 and other dynamic routing protocol

  • Support PIM-SM, PIM-DM, DVMRP and other multicast routing protocol

  • MPLS-based exchange routing and ECMP routing support load balanced

Primary Competitive Advantages:

  • Country of Origin

  • Distributorships Offered

  • Experienced Staff

  • Green Product

  • Guarantee/Warranty

  • International Approvals

  • Packaging

  • Price

  • Product Features

  • Product Performance

  • Prompt Delivery

  • Quality Approvals

  • Reputation

  • Service

  • Small Orders Accepted

Main Export Markets:

  • Asia

  • Central/South America

  • Mid East/Africa

  • North America

Payment Details:

  • Payment Terms:Telegraphic Transfer in Advance (Advance TT, T/T)

  • Minimum Order:1        Pieces

Delivery Details:


  • FOB Port:Shenzhen

  • FOB  Range: US$ 1 - US$ 900 per unit (Pieces)

  • Lead Time: 3        -        5        days
