Crawler Type Rice and Wheat Combine Harvester


Crawler Type Rice and Wheat Combine Harvester Basic Info.


Model NO.:4LZ-2.0D


Type:Horizontal Cut Harvester


Application:Rice, Wheat, Rape


Power Source:Diesel


Drive Type:Gear Drive






Crawler Type Rice and Wheat Combine Harvester Condition:New


Application Field:Agriculture


Colour:Red and White


Cutting Width:2000mm


Steering Type:Hydraulic Steering




Crawler Type Rice and Wheat Combine Harvester Product Description

    Favorable Advantages

1. 75HP diesel engine, 2 meters cutting width, Auto Transmission, high efficiency.
2. Double axial flow threshing cylinders and adjustable front & rear sieving plates ensure the grain more clean, less breakage and less loss.

3. Big width conveyer groove with innovated cutter bar lifting system can provide a more efficient feeding and a higher lifting level, convenient for working in paddy field and maintenance, and lower the noise and vibration.
4. Lower ground pressure, better for passing in paddy field.
5. Extremely strong Chassis; Excellent waterproof suspension wheel system; Easier turning & control with friction disc brake and special heavy-duty gearbox for hydraulic steering combine harvester.


Structure Style/Track Self-Walking Full-Feed

Applicability For Crop (Physical Height)mmPaddy, wheat: 500-1200Cole:601-700

Power Motivekw/rpm55/2400

Productivity of Pure Working Hourhm2/hPaddy,wheat:0.2-0.47Cole:0.1-0.3

Fuel Oil Consumption per Hectarekg/hm2≤38≤30

Outline Sizes in Working State

Structural WeightkgPaddy, wheat:2350Cole: 2450

Cutting Widthmm2000

Feed Volumekg/sPaddy, wheat:2.0Cole: 1.5

Minimum Gap of Off-Groundmm240

Style of Swerve/Hydraulic Style

Shift Modality/Automatic Mechanical Transmission +HST
Hydraulic Continuously Variable Transmission

Speed of Operation Forwardm/s0~2.88, 0~4.54, 0~7.56

Stroke of CuttermmII type

Auger Style of Cutting Table/Spiral Conveying

Outer Diameter of Auger of CuttingmmΦ470

Style of Reel/Eccentric Style

Diameter of ReelmmΦ900

No. of Plates of ReelPCS5

Conveyor Belt Style/Rake-Teeth Style

Threshing Roller Style/Tangential flow + Axial flow

Size of Threshing Roller(O.D. ×L)Front RollermmΦ540×650

Rear RollermmΦ540×1285
Concave Style/Grid Screen×2
Angle Range of Concave(°)227°
Fan Style/Centrifugal
Diameter of FanmmΦ328
Diameter of Grain Discharge augermmΦ123
Crew Distance of Grain Discharge augermm105
