Peanut Combine Harvester

Peanut Combine Harvester Basic Info

  • Application: Tubers, Peanut

  • Harvest method: Mining

  • Transmission: Soft Shaft

  • Certification: QS, SGS, ISO9001:2008, CE

  • Condition: New

  • Origin: China

  • Type: Horizontal Cut Harvester

  • Power Source: Tractor

  • Drive Type: Gear Drive

  • Portable Harvester Type: Backpack Type

  • Peanut Combine Harvester Color: Red

  • Peanut Combine Harvester Application Field: Agriculture

  • Specification: CE, ISO

Peanut Combine Harvester Product Description

Peanut Combine Harvester 4HB-2A Hot Selling in India
1. Hold the seedling, mining, transportation, picking combine harvester systems: practical, low loss.
2. The difference between the relative half-feed roller picking system: low power consumption, broken rate close to zero, high net picking rate, to ensure a complete straw seeding rate in order to facilitate recycling of straw seedlings.
3. By consisting of soil shaker, fans, vibrating screen, rubbing earthenware and hollow rotating sieve chain to have the efficient cleaning system: High peanut cleaning rate.
4. Wheeled travel system: self-propelled, self transfer, soil compaction light, to ensure easy peanut drop recycling and reproduction.
5. High performance to be used for most of the country dry crop patterns and soil condidtions.

Peanut Combine Harvester Technical Parameters

Power Matched30hp, 3-cylinder diesel engine
Structure TypeSuspension
Mining Depth100-200mm
Working Width600mm
Working Efficiency0.15 - 0.25ha./hr.
Overall Dimension(LxWxH)3970x1800x2550mm
Structure Weight1750kg
Total Loss Rate≤ 1%
Impurities Rate≤ 3%
Crashed Rate≤ 1%
Cleaning Rate≥ 96%
Seedling Rate of Complete≥ 98%


Peanut Combine Harvester.jpg
