Power Tiller 1lz-4.2 Once-Over Tillage Machine



Power Tiller 1lz-4.2 Once-Over Tillage Machine Basic Info.



Model NO.:1LZ-4.2



Type:Once-Over Tillage Machine



Tillage Machinery Application Field:Fisheries, Forestry



Farming Policy:Mountain Machinery



Power Source:Tractor



Operation:Tractor, Tractor



Tillage Machinery Traction Type:Three Point Mounted



Certification:ISO9001



Color:Many



Specification:many



Origin:Shan Dong China



Power Tiller 1lz-4.2 Once-Over Tillage Machine Product Description

    Once-over tillage machine
The Once-over tillage machine can complete the pulverize/Smash/Shatter , soil transporting, soil mixing, leveling before sowing, repression, and can be directly prepared flat seedbed, they can improve the efficacy, reduce the cost. After stubble ploughing, the organic soil quality contents rise, soil structure improves, the field improves.
The machine is suitable for growing out robust crop, and the same time you can Obtain greater benefits, All of these can be achieved depends on 1LZ series joint tillage machine, Working width from three point six meters to 7.2m, it can be content with different customer's requirement.
Power Tiller 1lz-4.2 Once-Over Tillage Machine Technical parameters:

Type1LZ-3.61LZ-4.21LZ-5.41LZ-7.2
Overall dimensions(mm)L   6600  660066007000
W3800440056007500
H1000100010001000
Max. Working width (m)3.64.25.47.2
Working depth(mm)80-14080-14080-14080-140
No. Of disc(PC)42506484
Disc of Type (mm)460×3460×3460×3460×3
Disc spacing(mm)170170170170
Weight(KG)2350268033204360
Productivity(Ha/h)2.282.663.334.44
LinkageTrailed
Trailed
Trans. Clearance(mm)≥160
≥160
Matched power(Hp)≥65≥80≥100≥120
