Multifunction Diesel Mini Rotary Tiller and Cultivator

Basic Info

• Model NO.: 1WG-3Q

• Application Field: Agriculture

• Power Source: Diesel

• Type: Multifunctional Pastoral Manage Machine

• Farming Policy: Paddy Field Machinery

• Operation: Movable Operation, Soil Preparation Machinery

Product Description

Specifications



1.Multifunction with cultivator parts.
2.Small order acceptable.
3.Factory price and high perfomance.
4.Easy for operation.



Product Description

                MULTIFUNCTION DIESEL POWER TILLER:





Introduction:



It's the domestic exclusive production with the advanced technology in China, reliable performance. The machine is applicable for the Vegetables' rotary tillage, weeding, cultivation, fertilization, in the hills, slopes, small field, garden, nursery, greenhouse etc. It's with the advantages of small volume, light weight, flexible performance, simple operation.





Some features:



1.It have excellent quality and reasonable price.

2.Compact structure and perfect cultivate performance.

3.High work efficiency.

4.It can be matched with kinds of knives.





Details:





Diesel tiller                    178F/186F diesel engine power mini rotary tiller

MODEL1WG-6Q10501WG-6Q1350

Engine model178F186F

Engine typeAir-cooled, 4-stroke,Vertical,Single-cylinder,  Direct injection combustion.

Bore×stroke(mm)78×6286×72

Displacement(cc)296418

Compression ratio20:119:1

Starting systemRecoil StartRecoil Start

Fuel oil tank volume (L)3.55.5

Lubrication oil capacity(L)1.11.65

Rated output power Hp/rpm6.0/360010.0/3600

Tilling width (mm)750~1050800~1350

Tilling depth (mm)≥100≥100

Gear shiftingReverse,0,1,2Reverse,0,1,2

Driving modeTriangle beltTriangle belt

Weight(kg)122131
