4LZ-0.8/1.0 Rice and Wheat Combine Harvester



4LZ-0.8/1.0 Rice and Wheat Combine Harvester Basic Info.



Model NO.:4LZ-0.8



Type:Horizontal Cut Harvester



Application:Rice, Corn, Wheat, Soybean, Straw



Reaper Power Source:Diesel



Harvest method:Cutting



Drive Type:Gear Drive



Reaper Transmission:Hard Shaft



Portable Harvester Type:Combine Harvester



Certification:ISO9001:2008



Color:as You Ask



Condition:New



Reaper Application Field:Agriculture, Livestock, Aquaculture



Cutting Width:1.2m



Package:Frame



Reaper Specification:2700*1420*1350



Origin:China



HS Code:8433510001



4LZ-0.8/1.0 Rice and Wheat Combine Harvester Product Description

    4LZ-0.8 COMBINE HARVESTER

Main Features: 1. Simple structure, strong ability to rake, durable, easy to operate and maintenance. 2. Especially suitable for the small field, land ,hills . 3. High efficiency and low oil consumption. 4. Good quality and reasonable price


SPECIFICATIONS FOR THE 4LZ-0.8 RICE HARVESTER
TYPE	CRAWLER,FULL FEEDING
MODEL	4LZ-0.8
OVERALL DIMENTIONS(mm)	2700X1420X1350
WEIGHT(kg)	350
WORKING WIDTH(m)	1.2
GROUND CLEARANCE(mm)	320
DIESEL ENGINE MODLE	192F
RATED POWER	9.2KW/12.52HP
RATED RPM(r/min)	3600
FUEL	DIESEL
ENGINE CYLINDER NOS.	1
STARTING METHOD	BY ELECTRICITY
THRESHING DRUM NOS	1
THRESHING DRUM DIA(mm)	350
BLOWER TYPE/DIA(mm)	CENTRAL AXIAL/280
REEL TYPE	ECCENTRIC TOOTH
CUTTING BLADE	TYPE II
CRAWLER TYPE	TRIANGLE RUBBER TRACK
CRAWLER SIZE(PITCH*NOS*WIDTH)mm	80*34*260
OPERATING EFFI.(ha/h)	0.09-0.12
FUEL CONSUMPTION(kg/ha)	13.5-22
TRANSMISSION TYPE	GEAR
BRAKING	BAND
LOST RATE(%)	NOT OVER 3
CLEAN RATE(5)	NOT OVER 7
