2017 Great Quality 15-25hprotary Tiller/Rotavator

2017 Great Quality 15-25hprotary Tiller/Rotavator Basic Info

  • Model NO.: RT 85/95/105/125/135

  • Application Field: Agriculture, Forestry

  • Power Source: Tractor

  • Traction Type: Traction

  • Arbor Configuration: Horizontal Axis

  • Tillage Machinery Color: Red

  • Working Width(Cm): 85-135mm

  • Tillage Machinery Blade Number: 16-32

  • Power Required: 15-30HP

  • ODM: Provide

  • Tillage Machinery Customer: Worldwide

  • Specification: CE & SGS

  • HS Code: 84322900

  • Type: Rotary Tiller

  • Tillage Machinery Farming Policy: Dry Cultivating Machinery

  • Operation: Soil Preparation Machinery, Continuous Running Operation

  • Drive Type: Chain Drive

  • Certification: SGS, CE, TUV

  • Colors: Red or Customer Request

  • Pto Input Speed(Rpm): 540r/Min

  • Tillage Machinery Tilling Depth(Cm): 8-12

  • OEM: Provide

  • Weight: 110-155kg

  • Origin: China

2017 Great Quality 15-25hprotary Tiller/Rotavator Product Description

PTO Shaft 3 Point Hitch Rotray Tiller (CE/SGS/TUV)
sized right for subcompact tractors and are designed to till soil for seedbed preparation. They are ideal for homeowner landscaping, small nurseries, gardens, small hobby farms, or medium-duty residential use.

2017 Great Quality 15-25hprotary Tiller/Rotavator Specification:
1.        3 point linkage
2.        Graphite casting iron gearbox
3.        Tractor power required: 15-25hp / 20-30hp

Mode RT-85 RT-95 RT-105 RT-115 RT-125 RT-135
Dimension(mm)  950*550*560 1050*550*560 1150*550*560 1250*550*560 1350*550*560 1450*550*560
Working width(cm) 85 95 105 115 125 135
PTO Input speed(rpm) 540r/min 540r/min 540r/min 540r/min 540r/min 540r/min
Weight(Kg) 110kg 115kg 125kg 135kg 145kg 155kg
Number of blades 16 16 20 24 28 32
Tilling depth(cm) 8-12 8-12 8-12 8-12 8-12 8-12
Packing size(mm) 1060*650*660 1160*650*660 1260*650*660 1360*650*660  1460*650*660 1560*650*660
Power required 15-25HP 15-25HP 15-25HP 20-30HP 20-30HP 20-30HP


PRODUCT ATTRIBUTE
1.       Transmission: chain driven.
2.       Gearbox is made of graphite casting iron.  Material performance is better. Not easy broken.
3.       The suspension plate shape is not easy to deform.
4.       Chain device hand adjustable. More easy and reliable.
5.       Side protection plates are added onto the rear deflection. This device prevents the soil flying out.     6.       The tilling height can be adjustable.


2017 Great Quality 15-25hprotary Tiller/Rotavator.jpg
